- 4 X 70 WRMS into 4 ohms @ 12.5 Vdc
- 4 X 92 WRMS into 4 ohms @ 14.4 Vdc
- 4 X 115 WRMS into 2 ohms @ 12.5 Vdc
- 4 X 152 WRMS into 2 ohms @ 14.4 Vdc
BRIDGED MONO – 2 CHANNEL
- 2 X 218 WRMS into 4 ohms @ 12.5 Vdc
- 2 X 300 WRMS into 4 ohms @ 14.4 Vdc
- Frequency response – 20-20,000 +/- 3dB THD < 0.5%
- Operating Voltage: 8V – 16V
- Current Draw (Music): 40 A
- Current Draw (Max): 80 A
- Recommended Fuse (Music): 40 A
- Total Efficiency: 79%
- Damping Factor: 200
- SNR: 91dB
- DSP Crossover HPF/LPF: 0 TO 20kHz
- Slope configurable 6/12/18/24/48dB
- DSP PEQ – 8 BANDS
- Q’s Adjustable from 0.05 – 20
- THD + N (10% Rated Power): 0.1%
- Product Dimensions (Inches / Millimeters): 8.875 x 4.0 x 1.4 in / 225.4 x 103 x 36 mm
